Sport 2S Falcon Kit with Rotax 582    USD $24,164 *

Sport 2S Falcon Kit without engine    USD $18,374 *

plus freight, and GST for Australian Customers.

(this is the basic kit with the B Box, 2 blade wooden prop, pull start, no instruments or oil injection)

FEATURES

* Dual CDI Electronic Ignition

* Dual Carburetor Engine

* Rugged Aluminium Steerable Nose Wheel

* Main Wheel Brakes

* Double Surface Wings with Streamlined Struts

* Extra ribs with Mylar Leading Edge Insert for Extra Firm Airfoil

* Increased Maximum Takeoff Weight of 996 lbs.

* Conventional 3-Axis Controls

* 68" Propeller for More Power with Less Noise

* Wider Tail Boom Accommodates up to 72" Propeller

* Even Wider Cockpit for Greater Pilot Comfort

* In-flight Adjustable Trim Control

* Tapered Stabiliser

* Tubular-Braced Tail

* Excellent Crosswind Capability

* Easy Handling and Responsive Control

* Short Take-off and Landing

* Quick Breakdown for Transport

* Quicksilver’s Famous Quality

* Easy-to-Assemble Kit (Average 40 to 60 Hours)

* Airspeed Indicator Included

SPECIFICATIONS

Powerplant - Rotax 582

No. of Cylinders - 2

Displacement - 580.7cc

Horsepower - 64 hp

Recommended TBO - 250 hrs.

Propeller - 68in x 36 in

Length - 18ft 1/2 in (5.48 mtrs)

Height - 8 ft (2.43 mtrs)

Wingspan - 31 ft (9.44 mtrs)

Wingarea - 174.1 sq ft

Wing loading - 5.74 lb/sq ft

Power loading - 15.63 lb/hp

Seats - 2

Minimum flight crew - 1

Empty weight * - 430 lb (195 kgs)

Useful load - 566 lb (256.7 kgs)

Payload w/full fuel * - 530 lb (214.7 kgs)

Max takeoff weight - 996 lb (451.7 kgs)

Fuel capacity - 6 U.S. gal - (22.7 Litres)

PERFORMANCE

Takeoff distance, ground roll - 73 Mtrs

Takeoff distance, 15 Mtr obstacle - 200 Mtrs

Rate of climb - 500 ft/min

Max level speed, sea level - 69 mph (60 kts)

Landing distance, 15 Mtr obstacle (with brake) -150 Mtr

Landing distance, ground roll (with brake) - 67 Mtr

Glide ratio - 5.5:1

Minimum sink rate - 660 ft/min

LIMITING AND RECOMMENDED SPEEDS

Vx (Best angle of climb) - 38 mph (33 kts)

Vy (Best rate of climb) - 40 mph (35 kts)

Va (Design maneuvering) - 70 mph (61 kts)

Vne (Never exceed) - 87 mph (76 kts)

Vs1 (Stall, power off) - 35 mph (30 kts)

Landing approach speed - 46 mph (42 kts)

CRUISE PERFORMANCE CHART

@ 55% power-5000 rpm - 55 mph (48 kts)

@ 65% power-5300 rpm - 58 mph (50 kts)

@ 75% power-5500 rpm - 61 mph (53 kts)

@ 100% power-6500 rpm -69mph (60 kts)

FUEL FLOW

@ 55% power (gph/mi) - 4.5/73

@ 65% power (gph/mi) - 5.0/69

@ 75% power (gph/mi) - 5.6/65

@ 100% power (gph/mi) - 7.5/53

Quicksilver AIrcraft Australia is the home of Quicksilver Aircraft (or Ultralights) for Australia, South Pacific and New Zealand, for aircraft,accessories and spare parts. We supply ultralight aircraft kits or factory built ultralights. We are the factory approved dealer of Quicksilver Manufacturing Inc USA. If you are looking for an ultralight aircraft with an impeccable safety record and an ultralight that is easy to fly, then Quicksilver Aircraft Australia is place to come to for your ultralight aircraft experience. If you would like to fly in a Quicksilver ultralight aircraft then give me a call.
